OJE-SH-105DM,095 - TE Connectivity

OJE-SH-105DM,095 Details

• Manufacturer Part Number:

  OJE-SH-105DM,095

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8536.41.00.20

• Manufacturer:

  TE Connectivity

• YTEOL:

  6.26

• Body Breadth:

  10.2 mm

• Body Height:

  14.7 mm

• Body Length or Diameter:

  18.2 mm

• Coil Current(DC)-Max:

  0.091 A

• Coil Operate Voltage(DC):

  3.5 V

• Coil Power:

  450 mW

• Coil Release Voltage(DC):

  0.25 V

• Coil Resistance:

  55 Ω

• Coil Voltage(DC)-Max:

  5 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  5A@250VAC

• Contact Current(AC)-Max:

  5 A

• Contact Current(DC)-Max:

  5 A

• Contact (DC) Max Rating R Load:

  5A@28VDC

• Contact Voltage(AC)-Max:

  250 V

• Contact Voltage(DC)-Max:

  28 V

• Contact/Output Supply Type:

  AC/DC

• Electrical Life:

  100000 Cycle(s)

• Mounting Feature:

  THROUGH HOLE-STRAIGHT

• Operate Time:

  10 ms

• Operating Temperature-Max:

  60 °C

• Operating Temperature-Min:

  -30 °C

• Physical Dimension:

  18.2mm x 10.2mm x 14.7mm

• Reference Standard:

  CSA; TUV; UL; VDE

• Relay Action:

  MOMENTARY

• Relay Function:

  SPST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  4 ms

• Surface Mount:

  NO

• Termination Type:

  SOLDER
