OJT-SS-112DM,000 - TE Connectivity

OJT-SS-112DM,000 Details

• Manufacturer Part Number:

  OJT-SS-112DM,000

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• Manufacturer:

  TE Connectivity

• YTEOL:

  6

• Body Breadth:

  10.2 mm

• Body Height:

  15.2 mm

• Body Length or Diameter:

  18.2 mm

• Coil Current(DC)-Max:

  0.038 A

• Coil Operate Voltage(DC):

  8.4 V

• Coil Power:

  450 mW

• Coil Release Voltage(DC):

  0.6 V

• Coil Resistance:

  320 Ω

• Coil Voltage(DC)-Max:

  12 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  5A@250VAC

• Contact Current(AC)-Max:

  5 A

• Contact Current(DC)-Max:

  5 A

• Contact Voltage(AC)-Max:

  250 V

• Contact/Output Supply Type:

  AC

• Dielectric Strength Between Coil and Contacts:

  4000 Vrms

• Dielectric Strength Between Open Contacts:

  750 Vrms

• Electrical Life:

  10000 Cycle(s)

• End Contact Material:

  SILVER TIN ALLOY

• Mounting Feature:

  PANEL MOUNT

• Operate Time:

  15 ms

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -30 °C

• Packing Method:

  BOX; TRAY

• Physical Dimension:

  18.2mm x 10.2mm x 14.7mm

• Reference Standard:

  CQC; TUV; UL; VDE

• Relay Action:

  MOMENTARY

• Relay Form:

  1 FORM A

• Relay Function:

  SPST

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  4 ms

• Sealing:

  RT2

• Surface Mount:

  NO

• Termination Type:

  SOLDER/QUICK CONNECT

• Weight:

  6 g
