OR3T1256PS240I-DB Details

• Manufacturer Part Number:

  OR3T1256PS240I-DB

• Pbfree Code:

  No

• Part Life Cycle Code:

  Active

• Part Package Code:

  QFP

• Package Description:

  HFQFP,

• Pin Count:

  240

• Reach Compliance Code:

  Unknown

• Manufacturer:

  Rochester Electronics LLC

• Combinatorial Delay of a CLB-Max:

  1.32 ns

• JESD-30 Code:

  S-PQFP-G240

• Length:

  32 mm

• Moisture Sensitivity Level:

  NOT SPECIFIED

• Number of CLBs:

  784

• Number of Equivalent Gates:

  186000

• Number of Terminals:

  240

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Organization:

  784 CLBS, 186000 GATES

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HFQFP

• Package Shape:

  SQUARE

• Package Style:

  FLATPACK, HEAT SINK/SLUG, FINE PITCH

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Programmable Logic Type:

  FIELD PROGRAMMABLE GATE ARRAY

• Qualification Status:

  COMMERCIAL

• Seated Height-Max:

  4.1 mm

• Supply Voltage-Max:

  3.6 V

• Supply Voltage-Min:

  3 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Temperature Grade:

  INDUSTRIAL

• Terminal Finish:

  NOT SPECIFIED

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Width:

  32 mm
