OTJTGLVANF-125.000000 - TAITIEN

OTJTGLVANF-125.000000 Details

• Manufacturer Part Number:

  OTJTGLVANF-125.000000

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SMD, 6 PIN

• Manufacturer:

  Taitien Electronics Co Ltd

• YTEOL:

  6

• Additional Feature:

  TRI-STATE; ENABLE/DISABLE FUNCTION; COMPLEMENTARY OUTPUT

• Fall Time-Max:

  1 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  50%

• JESD-609 Code:

  e4

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  6

• Operating Frequency-Nom:

  125 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  LVDS

• Package Body Material:

  CERAMIC

• Package Equivalence Code:

  DILCC6,.2

• Physical Dimension:

  7.0mm x 5.0mm x 1.45mm

• Rise Time-Max:

  1 ns

• Supply Current-Max:

  50 mA

• Supply Voltage-Max:

  2.625 V

• Supply Voltage-Min:

  2.375 V

• Supply Voltage-Nom:

  2.5 V

• Surface Mount:

  YES

• Symmetry-Max:

  55/45 %

• Terminal Finish:

  Gold (Au) - with Nickel (Ni) barrier
