P6KE15CA/B - Yageo Group

P6KE15CA/B Details

• Manufacturer Part Number:

  P6KE15CA/B

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DO-15, 2 PIN

• Country Of Origin:

  Mainland China, Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Factory Lead Time:

  20 Weeks, 2 Days

• Manufacturer:

  YAGEO Corporation

• YTEOL:

  6.16

• Additional Feature:

  EXCELLENT CLAMPING CAPABILITY, LOW ZENER IMPEDANCE, PRSM-MIN

• Breakdown Voltage-Max:

  15.8 V

• Breakdown Voltage-Min:

  14.3 V

• Breakdown Voltage-Nom:

  15.05 V

• Case Connection:

  ISOLATED

• Clamping Voltage-Max:

  21.2 V

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JEDEC-95 Code:

  DO-204AC

• JESD-30 Code:

  O-PALF-W2

• Moisture Sensitivity Level:

  1

• Non-rep Peak Rev Power Dis-Max:

  600 W

• Number of Elements:

  1

• Number of Terminals:

  2

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  ROUND

• Package Style:

  LONG FORM

• Peak Reflow Temperature (Cel):

  265

• Polarity:

  BIDIRECTIONAL

• Power Dissipation-Max:

  5 W

• Reference Standard:

  IEC-61000-4-2; UL CERTIFIED

• Rep Pk Reverse Voltage-Max:

  12.8 V

• Reverse Current-Max:

  1 µA

• Reverse Test Voltage:

  12.8 V

• Surface Mount:

  NO

• Technology:

  AVALANCHE

• Terminal Form:

  WIRE

• Terminal Position:

  AXIAL

• Time@Peak Reflow Temperature-Max (s):

  10
