P7805-Q12-S1R8-S - CUI Inc.

P7805-Q12-S1R8-S Details

• Manufacturer Part Number:

  P7805-Q12-S1R8-S

• Brand Name:

  CUI Inc

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  MODULE

• Package Description:

  SIP-3

• Pin Count:

  3

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  CUI Inc

• YTEOL:

  0

• Additional Feature:

  IT ALSO HAS -1.8V O/P VOLTAGE

• Analog IC - Other Type:

  SWITCHING REGULATOR

• Input Voltage-Max:

  28 V

• Input Voltage-Min:

  4.75 V

• Input Voltage-Nom:

  12 V

• JESD-30 Code:

  R-PSIP-T3

• Length:

  11.6 mm

• Number of Functions:

  1

• Number of Terminals:

  3

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.5 A

• Output Voltage-Max:

  1.854 V

• Output Voltage-Min:

  1.746 V

• Output Voltage-Nom:

  1.8 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  SIP

• Package Equivalence Code:

  SIP3,.08

• Package Shape:

  RECTANGULAR

• Package Style:

  IN-LINE

• Peak Reflow Temperature (Cel):

  260

• Seated Height-Max:

  10.45 mm

• Surface Mount:

  NO

• Switching Frequency-Max:

  450 kHz

• Temperature Grade:

  OTHER

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  SINGLE

• Time@Peak Reflow Temperature-Max (s):

  4

• Width:

  7.5 mm
