P82B96DGKRG4 - Texas Instruments

Description: I2C Logic Buffer 2.5V/3.3V/5V/9V/12V 8-Pin VSSOP T/R

Download P82B96DGKRG4 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
P82B96DGKRG4 - Texas Instruments PCB footprint - Small Outline Packages - Small Outline Packages - DGK  (S-PDSO-G8)
click to zoom
3D Models
P82B96DGKRG4 - Texas Instruments  - 3D model - Small Outline Packages - DGK  (S-PDSO-G8)
click to zoom

P82B96DGKRG4 Details

  • Manufacturer Part Number:

    P82B96DGKRG4

  • Brand Name:

    Texas Instruments

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    MSOP

  • Pin Count:

    8

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    15

  • Interface IC Type:

    BUS BUFFERS

  • JESD-30 Code:

    S-PDSO-G8

  • JESD-609 Code:

    e4

  • Length:

    3 mm

  • Moisture Sensitivity Level:

    1

  • Number of Functions:

    2

  • Number of Terminals:

    8

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    TSSOP

  • Package Equivalence Code:

    TSSOP8,.19

  • Package Shape:

    SQUARE

  • Package Style:

    SMALL OUTLINE, THIN PROFILE, SHRINK PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    1.1 mm

  • Supply Voltage-Max:

    15 V

  • Supply Voltage-Min:

    2 V

  • Supply Voltage-Nom:

    5 V

  • Surface Mount:

    YES

  • Technology:

    BIPOLAR

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.65 mm

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    3 mm

P82B96DGKRG4 Frequently Asked Questions (FAQs)

  • Texas Instruments provides a recommended PCB layout in the datasheet, but it's essential to follow good layout practices, such as keeping the input and output traces short, using a solid ground plane, and minimizing noise coupling. Additionally, consider using a 4-layer PCB with a dedicated power plane and a separate ground plane.
  • To ensure reliable operation, follow the recommended operating conditions, including voltage and current ratings. Implement thermal management techniques, such as heat sinks or thermal pads, to keep the device within the specified temperature range. Also, consider using a temperature sensor to monitor the device temperature and take corrective action if necessary.
  • Operating the P82B96DGKRG4 outside the recommended input voltage range can affect its performance, efficiency, and reliability. A lower input voltage may reduce the output voltage and increase the dropout voltage, while a higher input voltage may increase power dissipation and reduce the device's lifespan. Always operate the device within the recommended input voltage range to ensure optimal performance and reliability.
  • To minimize EMI and EMC issues, follow good design practices, such as using a shielded enclosure, keeping the device away from noise sources, and using EMI filters or ferrite beads on the input and output lines. Additionally, consider using a spread-spectrum clock or a clock frequency that is not a harmonic of the system clock to reduce EMI emissions.
  • A higher output capacitor value can improve the device's transient response and reduce output voltage ripple, but it may increase the device's startup time and reduce its efficiency. A lower output capacitor value can reduce the device's startup time and improve its efficiency, but it may compromise the device's transient response and increase output voltage ripple. Choose an output capacitor value that balances these trade-offs based on your specific application requirements.
