PA02M/883 - Apex Microtechnology

PA02M/883 Details

• Manufacturer Part Number:

  PA02M/883

• Pbfree Code:

  No

• Part Life Cycle Code:

  Active

• Part Package Code:

  TO-3

• Pin Count:

  8

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Manufacturer:

  Apex Microtechnology Inc

• YTEOL:

  4.62

• Amplifier Type:

  OPERATIONAL AMPLIFIER

• Architecture:

  VOLTAGE-FEEDBACK

• Average Bias Current-Max (IIB):

  0.0002 µA

• Bias Current-Max (IIB) @25C:

  0.0002 µA

• Common-mode Reject Ratio-Nom:

  70 dB

• Frequency Compensation:

  YES

• Input Offset Voltage-Max:

  11600 µV

• JESD-30 Code:

  O-MBFM-P8

• JESD-609 Code:

  e0

• Low-Bias:

  YES

• Low-Offset:

  NO

• Neg Supply Voltage Limit-Max:

  -19 V

• Neg Supply Voltage-Nom (Vsup):

  -15 V

• Number of Functions:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  METAL

• Package Equivalence Code:

  CAN8/9,.5FL

• Package Shape:

  ROUND

• Package Style:

  FLANGE MOUNT

• Power:

  YES

• Qualification Status:

  Not Qualified

• Screening Level:

  38535Q/M;38534H;883B

• Slew Rate-Min:

  8.5 V/us

• Supply Current-Max:

  40 mA

• Supply Voltage Limit-Max:

  19 V

• Supply Voltage-Nom (Vsup):

  15 V

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  MILITARY

• Terminal Finish:

  TIN LEAD

• Terminal Form:

  PIN/PEG

• Terminal Position:

  BOTTOM

• Unity Gain BW-Nom:

  4500

• Voltage Gain-Min:

  20000
