PA91 - Apex Microtechnology

PA91 Details

• Manufacturer Part Number:

  PA91

• Pbfree Code:

  No

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Part Package Code:

  SFM

• Package Description:

  POWER, SIP-12

• Pin Count:

  12

• Country Of Origin:

  USA

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Manufacturer:

  Apex Microtechnology Inc

• YTEOL:

  4.7

• Amplifier Type:

  OPERATIONAL AMPLIFIER

• Architecture:

  VOLTAGE-FEEDBACK

• Average Bias Current-Max (IIB):

  0.002 µA

• Bias Current-Max (IIB) @25C:

  0.002 µA

• Common-mode Reject Ratio-Nom:

  98 dB

• Frequency Compensation:

  YES (AVCL>=30)

• Input Offset Voltage-Max:

  2000 µV

• JESD-30 Code:

  R-PSFM-T12

• JESD-609 Code:

  e3

• Low-Bias:

  NO

• Low-Offset:

  NO

• Micropower:

  NO

• Neg Supply Voltage Limit-Max:

  -225 V

• Neg Supply Voltage-Nom (Vsup):

  -150 V

• Number of Functions:

  1

• Number of Terminals:

  12

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  SIP12,.1TB

• Package Shape:

  RECTANGULAR

• Package Style:

  FLANGE MOUNT

• Power:

  YES

• Qualification Status:

  Not Qualified

• Slew Rate-Min:

  240 V/us

• Slew Rate-Nom:

  300 V/us

• Supply Current-Max:

  14 mA

• Supply Voltage Limit-Max:

  225 V

• Supply Voltage-Nom (Vsup):

  150 V

• Surface Mount:

  NO

• Technology:

  MOS

• Temperature Grade:

  MILITARY

• Terminal Finish:

  MATTE TIN OVER NICKEL

• Terminal Form:

  THROUGH-HOLE

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  SINGLE

• Unity Gain BW-Nom:

  100000

• Voltage Gain-Min:

  50100

• Wideband:

  YES
