PAM8013AKR - Diodes Incorporated

PAM8013AKR Details

• Manufacturer Part Number:

  PAM8013AKR

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  UFLGA-1515, 9 PIN

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8542.33.00.01

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Diodes Incorporated

• YTEOL:

  8

• Consumer IC Type:

  CLASS D AUDIO AMPLIFIER

• Gain:

  18 dB

• JESD-30 Code:

  S-XBGA-N9

• JESD-609 Code:

  e4

• Length:

  1.5 mm

• Moisture Sensitivity Level:

  3

• Number of Channels:

  1

• Number of Functions:

  1

• Number of Terminals:

  9

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -25 °C

• Output Power-Nom:

  3 W

• Package Body Material:

  UNSPECIFIED

• Package Code:

  VFLGA

• Package Equivalence Code:

  LGA9,3X3,20

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY, VERY THIN PROFILE, FINE PITCH

• Peak Reflow Temperature (Cel):

  260

• Seated Height-Max:

  0.65 mm

• Supply Voltage-Max (Vsup):

  5.5 V

• Supply Voltage-Min (Vsup):

  2.8 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Finish:

  Nickel/Palladium/Gold (Ni/Pd/Au)

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  30

• Width:

  1.5 mm
