PCIB24W9F300A1/AA Frequently Asked Questions (FAQs)

• What is the recommended torque for the screw terminals?
  The recommended torque for the screw terminals is 0.5-1.0 Nm (4.4-8.8 in-lbs). It's essential to follow this torque specification to ensure reliable connections and prevent damage to the connector.
• Can I use this connector in a high-vibration environment?
  Yes, the PCIB24W9F300A1/AA is designed to withstand high-vibration environments. It meets the IEC 61373 Cat 2 vibration standard, which means it can operate reliably in applications with vibrations up to 15 g (147 m/s²) in the frequency range of 2-200 Hz.
• What is the maximum operating temperature for this connector?
  The PCIB24W9F300A1/AA has an operating temperature range of -40°C to +125°C (-40°F to +257°F). However, it's essential to note that the temperature rating may vary depending on the specific application and environmental conditions.
• Is this connector suitable for use in harsh environments, such as those with high humidity or exposure to chemicals?
  The PCIB24W9F300A1/AA has a sealed design that provides protection against moisture and contaminants. It meets the IP67 rating, which means it can withstand immersion in water up to 1 meter (3.3 feet) for 30 minutes. However, it's still important to evaluate the connector's performance in specific harsh environments and consider additional protection measures if necessary.
• Can I use this connector with a different PCB thickness?
  The PCIB24W9F300A1/AA is designed for use with PCBs having a thickness of 1.57 mm (0.062 in). However, it can be used with PCBs having a thickness of 1.0 mm to 2.36 mm (0.039 in to 0.093 in) with some adjustments. It's recommended to consult with Amphenol Positronic's technical support team for guidance on using the connector with non-standard PCB thicknesses.
