PCM3168APAPR - Texas Instruments

Description: 24-bit Multi-channel Audio CODEC 6ch-in/8ch-out with 96/192kHz sampling rate

Download PCM3168APAPR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
Send part feedback
Symbol
PCM3168APAPR - Texas Instruments - PCB symbol
click to zoom
PCB Footprints
PCM3168APAPR - Texas Instruments PCB footprint - Quad Flat Packages - Quad Flat Packages - pap64pin
click to zoom
3D Models
PCM3168APAPR - Texas Instruments - 3D model - Quad Flat Packages - pap64pin
click to zoom

PCM3168APAPR Details

  • Manufacturer Part Number:

    PCM3168APAPR

  • Brand Name:

    Texas Instruments

  • Pbfree Code:

    Yes

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Part Package Code:

    QFP

  • Pin Count:

    64

  • Country Of Origin:

    Taiwan

  • ECCN Code:

    EAR99

  • HTS Code:

    8542.39.00.90

  • Manufacturer:

    Texas Instruments

  • YTEOL:

    15

  • Consumer IC Type:

    CONSUMER CIRCUIT

  • JESD-30 Code:

    S-PQFP-G64

  • JESD-609 Code:

    e4

  • Length:

    10 mm

  • Moisture Sensitivity Level:

    3

  • Number of Functions:

    1

  • Number of Terminals:

    64

  • Operating Temperature-Max:

    85 °C

  • Operating Temperature-Min:

    -40 °C

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Code:

    HTFQFP

  • Package Equivalence Code:

    TQFP64,.47SQ

  • Package Shape:

    SQUARE

  • Package Style:

    FLATPACK, HEAT SINK/SLUG, THIN PROFILE, FINE PITCH

  • Peak Reflow Temperature (Cel):

    260

  • Qualification Status:

    Not Qualified

  • Seated Height-Max:

    1.2 mm

  • Supply Current-Max:

    210 mA

  • Supply Voltage-Max (Vsup):

    3.6 V

  • Supply Voltage-Min (Vsup):

    3 V

  • Surface Mount:

    YES

  • Temperature Grade:

    INDUSTRIAL

  • Terminal Finish:

    Nickel/Palladium/Gold (Ni/Pd/Au)

  • Terminal Form:

    GULL WING

  • Terminal Pitch:

    0.5 mm

  • Terminal Position:

    QUAD

  • Time@Peak Reflow Temperature-Max (s):

    30

  • Width:

    10 mm

PCM3168APAPR Frequently Asked Questions (FAQs)

  • The recommended power-up sequence is to apply VDD first, followed by AVDD, and then DVDD. This ensures that the internal voltage regulators are powered up in the correct order.
  • To configure the PCM3168 for master clock mode, set the MCLK pin to the desired clock frequency, and set the MCLKDIV pin to the desired clock divider ratio. Then, set the BCK pin to the desired bit clock frequency, and set the LRCK pin to the desired left-right clock frequency.
  • The maximum input voltage for the ADC inputs is 2.5V. Exceeding this voltage may cause damage to the device.
  • To optimize the PCM3168 for low power consumption, use the power-down modes (PDN and PDN2) to disable unused blocks, reduce the clock frequency, and use the dynamic voltage scaling feature to adjust the voltage supply to the minimum required for the application.
  • The recommended layout and routing for the PCM3168 involves keeping the analog and digital signals separate, using a solid ground plane, and minimizing the length of the clock and data lines to reduce noise and jitter.

Trust Checks

This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored

PCM3168APAPR Overview

Use the download button to access the PCM3168APAPR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like PCM31, or try a keyword search, such as Other Consumer ICs

About Texas Instruments

Texas Instruments (TI) designs and manufactures semiconductors and integrated circuits for a wide range of applications. The company's product portfolio includes analog chips, which are essential for managing power and signal functions in electronic devices, and embedded processors, which serve as the brains in various systems, enabling functionality in everything from industrial equipment to consumer electronics. TI's innovations in semiconductor technology have made it a leader in the industry.
