PDAC11001APFBT - Texas Instruments

PDAC11001APFBT Details

• Manufacturer Part Number:

  PDAC11001APFBT

• Brand Name:

  Texas Instruments

• Part Life Cycle Code:

  Obsolete

• Package Description:

  TQFP-48

• HTS Code:

  8542.39.00.40

• Date Of Intro:

  2019-11-16

• Manufacturer:

  Texas Instruments

• YTEOL:

  0

• Converter Type:

  D/A CONVERTER

• Input Bit Code:

  BINARY

• Input Format:

  SERIAL

• JESD-30 Code:

  S-PQFP-G48

• Length:

  7 mm

• Linearity Error-Max (EL):

  0.0004%

• Negative Supply Voltage-Nom:

  -15 V

• Number of Bits:

  20

• Number of Functions:

  1

• Number of Terminals:

  48

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TFQFP

• Package Shape:

  SQUARE

• Package Style:

  FLATPACK, THIN PROFILE, FINE PITCH

• Seated Height-Max:

  1.2 mm

• Settling Time-Nom (tstl):

  2.5 µs

• Supply Voltage-Nom:

  15 V

• Surface Mount:

  YES

• Temperature Grade:

  AUTOMOTIVE

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  7 mm
