PE1403M2Q_R1_00001 - PANJIT

PE1403M2Q_R1_00001 Details

• Manufacturer Part Number:

  PE1403M2Q_R1_00001

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  DFN-3

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Manufacturer:

  PanJit Semiconductor

• YTEOL:

  0

• Breakdown Voltage-Min:

  4 V

• Configuration:

  COMMON ANODE, 2 ELEMENTS

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JESD-30 Code:

  R-PBCC-N3

• Number of Elements:

  2

• Number of Terminals:

  3

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  CHIP CARRIER

• Polarity:

  UNIDIRECTIONAL

• Reference Standard:

  IEC-61000-4-2, 4-4, 4-5

• Rep Pk Reverse Voltage-Max:

  3.3 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Form:

  NO LEAD

• Terminal Position:

  BOTTOM
