PE3324C2A_R1_00001 - PANJIT

PE3324C2A_R1_00001 Details

• Manufacturer Part Number:

  PE3324C2A_R1_00001

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.50

• Date Of Intro:

  2018-06-27

• Manufacturer:

  PanJit Semiconductor

• YTEOL:

  7.11

• Breakdown Voltage-Max:

  29.5 V

• Breakdown Voltage-Min:

  26.5 V

• Configuration:

  COMMON ANODE, 2 ELEMENTS

• Diode Element Material:

  SILICON

• Diode Type:

  TRANS VOLTAGE SUPPRESSOR DIODE

• JESD-30 Code:

  R-PDSO-G3

• Number of Elements:

  2

• Number of Terminals:

  3

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Polarity:

  UNIDIRECTIONAL

• Rep Pk Reverse Voltage-Max:

  24 V

• Surface Mount:

  YES

• Technology:

  AVALANCHE

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL
