PI3740-00-LGMZ Frequently Asked Questions (FAQs)

• What is the recommended PCB layout and thermal management for optimal performance?
  Vicor recommends a 4-layer PCB with a solid ground plane, and thermal vias under the module to dissipate heat. A thermal interface material (TIM) should be used between the module and the heat sink.
• How do I ensure reliable start-up and shutdown of the module?
  To ensure reliable start-up and shutdown, Vicor recommends a soft-start circuit to limit inrush current, and a shutdown circuit to discharge the output capacitors. The enable pin should be driven high to enable the module, and low to disable it.
• What are the implications of input voltage transients on the module's performance?
  Input voltage transients can affect the module's performance and reliability. Vicor recommends using input capacitors to filter out transients, and ensuring that the input voltage remains within the specified range.
• How do I optimize the output voltage and current for my specific application?
  The output voltage and current can be optimized by adjusting the resistive divider network on the trim pin. Vicor provides a calculation tool to determine the optimal resistor values for the specific application.
• What are the EMI and RFI considerations for the module?
  The PI3740-00-LGMZ is designed to meet CISPR 22 Class B emissions limits. To minimize EMI and RFI, Vicor recommends using a shielded enclosure, and following good PCB layout practices to minimize radiation.
