PI7C9X1170BCLEX - Diodes Incorporated

PI7C9X1170BCLEX Details

• Manufacturer Part Number:

  PI7C9X1170BCLEX

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  TSSOP-16

• Country Of Origin:

  Mainland China

• ECCN Code:

  EAR99

• HTS Code:

  8542.31.00.01

• Factory Lead Time:

  28 Weeks

• Date Of Intro:

  2017-11-13

• Manufacturer:

  Diodes Incorporated

• YTEOL:

  6

• Additional Feature:

  ALSO OPERATES AT 1.8V AND 2.5V NOMINAL

• Boundary Scan:

  NO

• Bus Compatibility:

  I2C; IRDA; RS-232; RS-485; SPI

• Clock Frequency-Max:

  64 MHz

• Communication Protocol:

  ASYNC, BIT; SYNC, BYTE

• Data Transfer Rate-Max:

  4.125 MBps

• JESD-30 Code:

  R-PDSO-G16

• Length:

  5 mm

• Low Power Mode:

  NO

• Moisture Sensitivity Level:

  1

• Number of Serial I/Os:

  1

• Number of Terminals:

  16

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  TSSOP

• Package Equivalence Code:

  TSSOP16,.25

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, THIN PROFILE, SHRINK PITCH

• Peak Reflow Temperature (Cel):

  255

• Seated Height-Max:

  1.2 mm

• Supply Current-Max:

  6 mA

• Supply Voltage-Max:

  3.63 V

• Supply Voltage-Min:

  2.97 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  GULL WING

• Terminal Pitch:

  0.65 mm

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  30

• Width:

  4.4 mm

• uPs/uCs/Peripheral ICs Type:

  SERIAL IO/COMMUNICATION CONTROLLER, I2C BUS
