PI7C9X2G404ELZXAE - Diodes Incorporated

PI7C9X2G404ELZXAE Details

• Manufacturer Part Number:

  PI7C9X2G404ELZXAE

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  AQFN-136

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8542.31.00.01

• Factory Lead Time:

  20 Weeks

• Date Of Intro:

  2017-09-20

• Manufacturer:

  Diodes Incorporated

• YTEOL:

  8

• Bus Compatibility:

  PCI; SMBUS

• Clock Frequency-Max:

  100 MHz

• Data Transfer Rate-Max:

  625 MBps

• JESD-30 Code:

  S-XBCC-N136

• Length:

  10 mm

• Number of Terminals:

  136

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  UNSPECIFIED

• Package Code:

  HVBCC

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• Peak Reflow Temperature (Cel):

  260

• Seated Height-Max:

  0.85 mm

• Supply Voltage-Max:

  1.1 V

• Supply Voltage-Min:

  0.95 V

• Supply Voltage-Nom:

  1 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  10

• Width:

  10 mm

• uPs/uCs/Peripheral ICs Type:

  BUS CONTROLLER, PCI
