PJE138K_R1_00001 - PANJIT

Description: MOSFET /8KT/TR/7"/HF/4K/SOT-523/MOS/SOT/NFET-50TBMN/NF50TB-QI01/PJ///

Download PJE138K_R1_00001 Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
PJE138K_R1_00001 - PANJIT PCB footprint - SO Transistor Flat Lead - SO Transistor Flat Lead - PJE138K_R1_00001
click to zoom
3D Models
PJE138K_R1_00001 - PANJIT  - 3D model - SO Transistor Flat Lead - PJE138K_R1_00001
click to zoom

PJE138K_R1_00001 Details

  • Manufacturer Part Number:

    PJE138K_R1_00001

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • Package Description:

    GREEN, PLASTIC PACKAGE-3

  • ECCN Code:

    EAR99

  • Manufacturer:

    PanJit Semiconductor

  • YTEOL:

    6

  • Configuration:

    SINGLE WITH BUILT-IN DIODE

  • DS Breakdown Voltage-Min:

    50 V

  • Drain Current-Max (ID):

    0.35 A

  • Drain-source On Resistance-Max:

    1.6 Ω

  • FET Technology:

    METAL-OXIDE SEMICONDUCTOR

  • Feedback Cap-Max (Crss):

    5 pF

  • JESD-30 Code:

    R-PDSO-F3

  • Number of Elements:

    1

  • Number of Terminals:

    3

  • Operating Mode:

    ENHANCEMENT MODE

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Polarity/Channel Type:

    N-CHANNEL

  • Surface Mount:

    YES

  • Terminal Form:

    FLAT

  • Terminal Position:

    DUAL

  • Transistor Application:

    SWITCHING

  • Transistor Element Material:

    SILICON
