PMCS1101A2UQDR - Texas Instruments

PMCS1101A2UQDR Details

• Manufacturer Part Number:

  PMCS1101A2UQDR

• Brand Name:

  Texas Instruments

• Part Life Cycle Code:

  Obsolete

• Package Description:

  SOIC-8

• Date Of Intro:

  2019-09-20

• Manufacturer:

  Texas Instruments

• YTEOL:

  0

• Body Breadth:

  3.895 mm

• Body Height:

  1.75 mm

• Body Length or Diameter:

  4.905 mm

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  8

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output:

  ANALOG

• Output Type:

  ANALOG VOLTAGE

• Package Body Material:

  PLASTIC/EPOXY

• Package Equivalence Code:

  SOP8,.25

• Package Shape/Style:

  RECTANGULAR

• Sensors/Transducers Type:

  CURRENT SENSOR

• Supply Voltage-Max:

  5.5 V

• Supply Voltage-Min:

  3 V

• Surface Mount:

  YES
