PS2502L-2-A - Renesas Electronics

PS2502L-2-A Details

• Manufacturer Part Number:

  PS2502L-2-A

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• HTS Code:

  8541.40.80.00

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• Additional Feature:

  UL RECOGNIZED

• Coll-Emtr Bkdn Voltage-Min:

  40 V

• Configuration:

  SEPARATE, 2 CHANNELS

• Current Transfer Ratio-Min:

  200%

• Current Transfer Ratio-Nom:

  2000%

• Dark Current-Max:

  400 nA

• Forward Current-Max:

  0.08 A

• Forward Voltage-Max:

  1.4 V

• Isolation Voltage-Max:

  5000 V

• JESD-609 Code:

  e1

• Mounting Feature:

  SURFACE MOUNT

• Number of Elements:

  2

• On-State Current-Max:

  0.16 A

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -55 °C

• Optoelectronic Device Type:

  DARLINGTON OUTPUT OPTOCOUPLER

• Packing Method:

  MAGAZINE

• Power Dissipation-Max:

  0.16 W

• Response Time-Max:

  0.0001 s

• Surface Mount:

  YES

• Terminal Finish:

  Tin/Silver/Copper (Sn/Ag/Cu)
