PS2561F-1 - Renesas Electronics

PS2561F-1 Details

• Manufacturer Part Number:

  PS2561F-1

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• HTS Code:

  8541.40.80.00

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  5

• Coll-Emtr Bkdn Voltage-Min:

  80 V

• Configuration:

  SINGLE

• Current Transfer Ratio-Min:

  60%

• Current Transfer Ratio-Nom:

  450%

• Dark Current-Max:

  100 nA

• Forward Current-Max:

  0.03 A

• Forward Voltage-Max:

  1.4 V

• Isolation Voltage-Max:

  5000 V

• Mounting Feature:

  THROUGH HOLE MOUNT

• Number of Elements:

  1

• On-State Current-Max:

  0.04 A

• Operating Temperature-Max:

  110 °C

• Operating Temperature-Min:

  -55 °C

• Optoelectronic Device Type:

  TRANSISTOR OUTPUT OPTOCOUPLER

• Power Dissipation-Max:

  0.15 W

• Surface Mount:

  NO
