PT271012 - TE Connectivity

PT271012 Details

• Manufacturer Part Number:

  PT271012

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• Factory Lead Time:

  27 Weeks, 5 Days

• Manufacturer:

  TE Connectivity

• YTEOL:

  7

• Body Breadth:

  22.5 mm

• Body Height:

  30 mm

• Body Length or Diameter:

  28 mm

• Coil Current(DC)-Max:

  0.063 A

• Coil Operate Voltage(DC):

  9 V

• Coil Power:

  750 mW

• Coil Release Voltage(DC):

  1.2 V

• Coil Resistance:

  192 Ω

• Coil Voltage(DC)-Max:

  12 V

• Coil/Input Supply Type:

  DC

• Contact (AC) Max Rating R Load:

  12A@250VAC

• Contact Current(AC)-Max:

  12 A

• Contact Current(DC)-Max:

  12 A

• Contact Voltage(AC)-Max:

  400 V

• Contact/Output Supply Type:

  AC/DC

• Dielectric Strength Between Coil and Contacts:

  2500 Vrms

• Dielectric Strength Between Open Contacts:

  1200 Vrms

• End Contact Material:

  SILVER NICKEL

• Mounting Feature:

  PANEL MOUNT

• Operate Time:

  20 ms

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BOX; TUBE

• Physical Dimension:

  28 X 22.5 X 30

• Reference Standard:

  UL; VDE

• Relay Action:

  MOMENTARY

• Relay Form:

  2 FORM C

• Relay Function:

  DPDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  15 ms

• Surface Mount:

  NO

• Termination Type:

  SOLDER/QUICK CONNECT

• Weight:

  30 g
