PT371730 - TE Connectivity

PT371730 Details

• Manufacturer Part Number:

  PT371730

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  ROHS COMPLIANT

• ECCN Code:

  EAR99

• Factory Lead Time:

  27 Weeks, 5 Days

• Manufacturer:

  TE Connectivity

• YTEOL:

  6.87

• Additional Feature:

  COIL OPERATE VOLTAGE(AC): 207.0 V , COIL RELEASE VOLTAGE(AC): 69.0 V; RELEASE TIME WITH DIODE

• Body Breadth:

  22.5 mm

• Body Height:

  30 mm

• Body Length or Diameter:

  28 mm

• Coil Current(AC)-Max:

  0.004 A

• Coil Power:

  1000 mW

• Coil Release Voltage(AC):

  69 V

• Coil Resistance:

  19465 Ω

• Coil Voltage(AC)-Max:

  230 V

• Coil Voltage-Nom:

  230 V

• Coil/Input Supply Type:

  AC

• Contact (AC) Max Power Rating R Load:

  2500VA@400VAC

• Contact (AC) Max Rating R Load:

  10A@400VAC

• Contact Current(AC)-Max:

  10 A

• Contact Current(DC)-Max:

  10 A

• Contact Voltage(AC)-Max:

  400 V

• Contact/Output Supply Type:

  AC

• Dielectric Strength Between Coil and Contacts:

  2500 Vrms

• Dielectric Strength Between Open Contacts:

  1200 Vrms

• Electrical Life:

  100000 Cycle(s)

• End Contact Material:

  SILVER NICKEL

• Mounting Feature:

  PANEL MOUNT

• Number of Terminals:

  11

• Operate Time:

  23 ms

• Operating Temperature-Max:

  70 °C

• Operating Temperature-Min:

  -40 °C

• Packing Method:

  BOX; TUBE

• Physical Dimension:

  28 X 22.5 X 30

• Reference Standard:

  UL; VDE

• Relay Action:

  MOMENTARY

• Relay Form:

  3 FORM C

• Relay Function:

  3PDT

• Relay Type:

  POWER/SIGNAL RELAY

• Release Time:

  15 ms

• Sealing:

  RT2

• Surface Mount:

  NO

• Terminal Length:

  0.004099568199136398 inch

• Termination Type:

  SOLDER/QUICK CONNECT

• Weight:

  30 g
