Bourns provides a recommended PCB layout and land pattern in their application note AN164, which can be found on their website. It's essential to follow this layout to ensure proper thermal performance and to prevent overheating.
To ensure reliability, it's crucial to follow the recommended derating curves for temperature and power dissipation. Additionally, consider using a thermally conductive interface material, such as thermal tape or thermal grease, to improve heat transfer between the device and the heat sink.
While the datasheet specifies a maximum input voltage of 30V, it's essential to consider the voltage derating curve to ensure the device operates within its safe operating area. Always check the device's voltage rating and derating curve to ensure reliable operation.
The PTH902-030F-103B2 is not hermetically sealed, so it's not recommended for use in high-humidity environments. If you need a device that can operate in humid conditions, consider using a hermetically sealed or moisture-resistant alternative.
The lead time for PTH902-030F-103B2 can vary depending on the supplier, quantity, and availability. Typically, the lead time ranges from 4-12 weeks. It's recommended to check with authorized distributors or Bourns Inc directly for the most up-to-date lead time information.
