PTN3222HM - NXP

PTN3222HM Details

• Manufacturer Part Number:

  PTN3222HM

• Part Life Cycle Code:

  Active

• Package Description:

  XQFN-12

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Manufacturer:

  NXP Semiconductors

• Additional Feature:

  IT CAN ALSO OPEARTE WITH 1.8V

• Differential Output:

  NO

• Driver Number of Bits:

  1

• Input Characteristics:

  STANDARD

• Interface IC Type:

  LINE TRANSCEIVER

• Interface Standard:

  GENERAL PURPOSE

• JESD-30 Code:

  R-PQCC-N12

• Length:

  2.2 mm

• Number of Functions:

  1

• Number of Terminals:

  12

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  XQCCN

• Package Equivalence Code:

  LCC12,.07X.08,16

• Package Shape:

  RECTANGULAR

• Package Style:

  CHIP CARRIER, EXTREMELY THIN PROFILE

• Receive Delay-Max:

  3 ns

• Receiver Number of Bits:

  1

• Seated Height-Max:

  0.5 mm

• Supply Current-Max:

  55 mA

• Supply Voltage-Max:

  3.63 V

• Supply Voltage-Min:

  2.85 V

• Supply Voltage-Nom:

  3 V

• Surface Mount:

  YES

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.4 mm

• Terminal Position:

  QUAD

• Transmit Delay-Max:

  3 ns

• Width:

  1.75 mm
