PUCC12050DVE - Texas Instruments

PUCC12050DVE Details

• Manufacturer Part Number:

  PUCC12050DVE

• Brand Name:

  Texas Instruments

• Part Life Cycle Code:

  Active Unconfirmed

• Package Description:

  SO-MOD-16

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Date Of Intro:

  2019-09-20

• Manufacturer:

  Texas Instruments

• YTEOL:

  2

• Additional Feature:

  ALSO AVAILABLE IN 5V NOMINAL OUTPUT

• Analog IC - Other Type:

  SWITCHING REGULATOR

• Input Voltage-Max:

  5.5 V

• Input Voltage-Min:

  4.5 V

• Input Voltage-Nom:

  5 V

• JESD-30 Code:

  R-PDSO-G16

• Length:

  10.3 mm

• Number of Functions:

  1

• Number of Terminals:

  16

• Operating Temperature-Max:

  125 °C

• Operating Temperature-Min:

  -40 °C

• Output Voltage-Max:

  5 V

• Output Voltage-Min:

  3.3 V

• Output Voltage-Nom:

  3.3 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  HSOP

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE, HEAT SINK/SLUG

• Seated Height-Max:

  2.65 mm

• Surface Mount:

  YES

• Temperature Grade:

  AUTOMOTIVE

• Terminal Form:

  GULL WING

• Terminal Pitch:

  1.27 mm

• Terminal Position:

  DUAL

• Width:

  7.5 mm
