PUMD15-QX - Nexperia

PUMD15-QX Details

• Manufacturer Part Number:

  PUMD15-QX

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SC-88, SOT-363, TSSOP-6

• ECCN Code:

  EAR99

• Manufacturer:

  Nexperia

• YTEOL:

  7

• Additional Feature:

  BUILT IN BIAS RESISTANCE RATIO IS 1

• Collector Current-Max (IC):

  0.1 A

• Collector-Base Capacitance-Max:

  2.5 pF

• Collector-Emitter Voltage-Max:

  50 V

• Configuration:

  SEPARATE, 2 ELEMENTS WITH BUILT-IN RESISTOR

• DC Current Gain-Min (hFE):

  30

• JESD-30 Code:

  R-PDSO-G6

• Number of Elements:

  2

• Number of Terminals:

  6

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -65 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Polarity/Channel Type:

  NPN AND PNP

• Power Dissipation-Max (Abs):

  0.3 W

• Reference Standard:

  AEC-Q101; IEC-60134

• Surface Mount:

  YES

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON

• Transition Frequency-Nom (fT):

  230 MHz

• VCEsat-Max:

  0.15 V
