PUMH24 Details

• Manufacturer Part Number:

  PUMH24

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  SC-88, SOT-363, 6 PIN

• Country Of Origin:

  Malaysia

• ECCN Code:

  EAR99

• Date Of Intro:

  2017-02-01

• Manufacturer:

  Nexperia

• YTEOL:

  7

• Additional Feature:

  BUILT IN BIAS RESISTOR RATIO 1

• Collector Current-Max (IC):

  0.02 A

• Collector-Base Capacitance-Max:

  2.5 pF

• Collector-Emitter Voltage-Max:

  50 V

• Configuration:

  SEPARATE, 2 ELEMENTS WITH BUILT-IN RESISTOR

• DC Current Gain-Min (hFE):

  80

• JESD-30 Code:

  R-PDSO-G6

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Number of Elements:

  2

• Number of Terminals:

  6

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -65 °C

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Peak Reflow Temperature (Cel):

  260

• Polarity/Channel Type:

  NPN

• Power Dissipation-Max (Abs):

  0.3 W

• Reference Standard:

  IEC-60134

• Surface Mount:

  YES

• Terminal Finish:

  Tin (Sn)

• Terminal Form:

  GULL WING

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  40

• Transistor Application:

  SWITCHING

• Transistor Element Material:

  SILICON

• VCEsat-Max:

  0.15 V
