PUUP3J - Taiwan Semiconductor

PUUP3J Details

• Manufacturer Part Number:

  PUUP3J

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Country Of Origin:

  Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8541.10.00.80

• Factory Lead Time:

  12 Weeks

• Manufacturer:

  Taiwan Semiconductor

• YTEOL:

  6

• Additional Feature:

  FREE WHEELING DIODE, LOW POWER LOSS, SNUBBER DIODE

• Application:

  EFFICIENCY

• Case Connection:

  CATHODE

• Configuration:

  SINGLE

• Diode Element Material:

  SILICON

• Diode Type:

  RECTIFIER DIODE

• Forward Voltage-Max (VF):

  1.7 V

• JEDEC-95 Code:

  TO-277A

• JESD-30 Code:

  R-PDSO-F3

• JESD-609 Code:

  e3

• Moisture Sensitivity Level:

  1

• Non-rep Pk Forward Current-Max:

  55 A

• Number of Elements:

  1

• Number of Phases:

  1

• Number of Terminals:

  3

• Operating Temperature-Max:

  150 °C

• Operating Temperature-Min:

  -55 °C

• Output Current-Max:

  3 A

• Package Body Material:

  PLASTIC/EPOXY

• Package Shape:

  RECTANGULAR

• Package Style:

  SMALL OUTLINE

• Reference Standard:

  IEC-61249-2-21

• Rep Pk Reverse Voltage-Max:

  600 V

• Reverse Current-Max:

  2 µA

• Reverse Recovery Time-Max:

  0.025 µs

• Reverse Test Voltage:

  600 V

• Surface Mount:

  YES

• Terminal Finish:

  Matte Tin (Sn)

• Terminal Form:

  FLAT

• Terminal Position:

  DUAL
