QA152D - Mornsun Power

QA152D Details

• Manufacturer Part Number:

  QA152D

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  Module-8

• ECCN Code:

  EAR99

• Manufacturer:

  MORNSUN

• YTEOL:

  5

• Additional Feature:

  IT IS ALSO HAVING -9V OUTPUT VOLTAGE(-8.1 TO -9.9)

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  EN, IEC

• Control Mode:

  VOLTAGE-MODE

• Efficiency (Main Output):

  83%

• Input Voltage-Max:

  16.5 V

• Input Voltage-Min:

  13.5 V

• Input Voltage-Nom:

  15 V

• JESD-30 Code:

  R-PDMA-P8

• Length:

  31.6 mm

• Load Regulation-Max:

  10%

• Number of Functions:

  1

• Number of Outputs:

  2

• Number of Terminals:

  8

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.25 A

• Output Voltage-Max:

  16.5 V

• Output Voltage-Min:

  13.5 V

• Output Voltage-Nom:

  15 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  INPUT UNDER VOLTAGE

• Ripple Voltage (Main Out):

  0.02828 Vrms

• Seated Height-Max:

  10.7 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  INDUSTRIAL

• Terminal Form:

  PIN/PEG

• Terminal Pitch:

  2.54 mm

• Terminal Position:

  DUAL

• Total Power Output-Max:

  4.8 W

• Trim/Adjustable Output:

  NO

• Width:

  20.3 mm
