QAT-0+ Details

  • Manufacturer Part Number:

    QAT-0+

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Active

  • ECCN Code:

    EAR99

  • Manufacturer:

    Mini-Circuits

  • YTEOL:

    8

  • Attenuation-Nom:

    0.9 dB

  • Characteristic Impedance:

    50 Ω

  • Construction:

    COMPONENT

  • Input Power-Max (CW):

    33.01 dBm

  • Mounting Feature:

    SURFACE MOUNT

  • Number of Terminals:

    6

  • Operating Frequency-Max:

    50000 MHz

  • RF/Microwave Device Type:

    FIXED ATTENUATOR

  • Surface Mount:

    YES

  • VSWR-Max:

    1.39

QAT-0+ Frequently Asked Questions (FAQs)

  • Mini-Circuits provides a recommended PCB layout and footprint in their application note AN-60-014, which can be found on their website. It's essential to follow this layout to ensure optimal performance and minimize parasitic effects.
  • To achieve the specified return loss and VSWR, it's crucial to use a well-designed PCB with a controlled impedance, ensure proper soldering and assembly, and use a suitable connector or interface. Additionally, the QAT-0+ should be terminated with a 50-ohm load to achieve the specified return loss.
  • The maximum power handling of QAT-0+ is not explicitly stated in the datasheet. However, according to Mini-Circuits, the device can handle up to 1W of continuous power, but this may vary depending on the specific application and operating conditions. It's recommended to consult with Mini-Circuits' technical support for specific power handling requirements.
  • While QAT-0+ is designed for 50-ohm systems, it can be used in non-50-ohm systems with some limitations. However, the device's performance may degrade, and the return loss and VSWR may not meet the specified values. It's recommended to consult with Mini-Circuits' technical support to determine the feasibility of using QAT-0+ in a non-50-ohm system.
  • To troubleshoot issues with QAT-0+, start by verifying the PCB layout and assembly, ensuring proper soldering and termination. Check the input and output signals using a spectrum analyzer or oscilloscope to identify any anomalies. Consult Mini-Circuits' application notes and technical support for guidance on troubleshooting specific issues.
