Qorvo provides a recommended PCB layout in their application note AN-2171, which includes guidelines for component placement, trace routing, and grounding to minimize parasitics and ensure optimal performance.
Optimizing biasing for maximum linearity involves adjusting the voltage and current bias points to minimize distortion. Qorvo recommends using a bias tee or a resistive divider network to set the bias voltage, and adjusting the current bias to achieve the desired output power and linearity.
While the datasheet specifies an operating temperature range of -40°C to +85°C, Qorvo recommends derating the device's power output and operating temperature to ensure reliable operation over the full temperature range. Consult Qorvo's application notes for more information.
Qorvo recommends following a structured troubleshooting approach, including checking the PCB layout, component values, and biasing conditions. Use a spectrum analyzer to identify oscillation frequencies, and consult Qorvo's application notes and technical support resources for guidance on resolving common issues.
Qorvo recommends following standard ESD protection practices, including using ESD-sensitive handling and storage procedures, and incorporating ESD protection devices such as TVS diodes or ESD protection arrays in the PCB design.
Trust Checks
This model has been built in collaboration with the manufacturer.
Manufacturer Collaborated
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
QPA2935 Overview
Use the download button to access the QPA2935 schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like QPA29,
or try a keyword search, such as RF/Microwave Amplifiers
About Qorvo
Qorvo is a prominent American semiconductor company that specializes in the design and manufacturing of radio frequency (RF) solutions. The company was formed in 2015 through the merger of TriQuint Semiconductor and RF Micro Devices. Qorvo's product portfolio encompasses a wide range of RF components and semiconductor technologies used in various applications, including wireless communications, aerospace and defense, and IoT (Internet of Things) devices.
