Qorvo provides a recommended PCB layout and thermal management guide in their application note AN-2171, which includes guidelines for thermal vias, heat sinks, and PCB stack-up to ensure optimal performance and thermal dissipation.
Qorvo offers a free online tool called Qorvo's GaN Device Model and S-Parameter Library, which provides a comprehensive set of device models and S-parameters for the QPC7336SR. This tool can be used to optimize the biasing and matching networks for specific applications and frequencies.
While the datasheet specifies an operating temperature range of -40°C to 85°C, Qorvo recommends derating the device's power output above 70°C to ensure reliable operation and prevent thermal runaway. Consult with Qorvo's application engineers for specific guidance on temperature derating.
Qorvo provides guidelines for EMC and EMI compliance in their application note AN-2172, which includes recommendations for shielding, filtering, and layout techniques to minimize electromagnetic radiation and susceptibility.
Qorvo recommends following the standard ESD handling and storage procedures for GaN devices, including the use of anti-static bags, wrist straps, and workbenches to prevent electrostatic discharge damage. Consult with Qorvo's application engineers for specific guidance on storage and handling.
