- Part Number QPQ1270TR7
- Manufacturer Qorvo
- Pin Count 9
- Part Category Integrated Circuit
- Package Category Other
- Footprint Name Other - QPQ1270TR7-4
- Released Date Dec 23, 2024
- Last Modified Date Mar 9, 2026 5:25 PM UTC
- Pinout / Pin List Click Here (Member Only)
QPQ1270TR7 Details
-
Manufacturer Part Number:
QPQ1270TR7
-
Rohs Code:
Yes
-
Part Life Cycle Code:
Active
-
Factory Lead Time:
16 Weeks
-
Manufacturer:
Qorvo
-
YTEOL:
0.48
-
Filter Type:
DUPLEXER
-
Height:
1.015 mm
-
Insertion Loss (Rx):
3 dB
-
Insertion Loss (Tx):
3.8 dB
-
JESD-609 Code:
e4
QPQ1270TR7 Frequently Asked Questions (FAQs)
-
Qorvo recommends a 4-layer PCB with a solid ground plane, and thermal vias under the package to dissipate heat. A thermal pad on the bottom of the package should be connected to a large copper area on the PCB to improve heat dissipation.
-
Qorvo provides a reference design and simulation models for the QPQ1270TR7. Engineers can use these resources to optimize the input and output matching networks for their specific application using simulation software such as ADS or AWR Microwave Office.
-
Qorvo recommends a gradual biasing procedure to avoid thermal runaway. The device should be biased in a sequence of Vd, Vg, and then Id. The tuning procedure involves adjusting the input and output matching networks for optimal performance.
-
Engineers should ensure that the device operates within its specified voltage, current, and power ratings. The device's temperature should also be monitored to prevent overheating. Qorvo provides a SOA graph in the datasheet to help engineers ensure safe operation.
-
Qorvo performs a range of reliability tests, including temperature cycling, humidity testing, and electrical overstress testing. The device is also qualified according to the Automotive Electronics Council (AEC) Q100 and Q101 standards.
