XP Power recommends a PCB layout with a large copper area connected to the module's thermal pad to dissipate heat efficiently. A minimum of 2 oz copper thickness is recommended, and the copper area should be at least 1 inch x 1 inch in size.
Yes, the QSB10024S15 is designed to withstand high-vibration environments. It meets the IEC 60068-2-6 vibration test standard, which simulates vibrations up to 10 G peak acceleration. However, it's recommended to consult with XP Power's application engineers to ensure the module meets the specific vibration requirements of your application.
To ensure EMC, XP Power recommends following the module's layout and grounding guidelines, using a metal enclosure, and adding EMI filters or shielding if necessary. Additionally, the module's input and output cables should be kept as short as possible and routed away from noise sources.
The QSB10024S15 has a built-in undervoltage lockout (UVLO) feature that shuts down the module when the input voltage falls below 12 V. When the input voltage recovers, the module will automatically restart. However, the module's behavior during brownout or dropout may vary depending on the specific application and system requirements.
Yes, the QSB10024S15 can be paralleled to increase the output power. However, it's essential to ensure that the modules are identical, and the output voltages are matched to within 1% of each other. Additionally, a master-slave configuration is recommended to prevent oscillation and ensure stable operation.
