QSB35024S12 Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal thermal performance?
  XP Power recommends a PCB layout with a large copper area connected to the module's thermal pad to dissipate heat efficiently. A minimum of 2 oz copper thickness is recommended, and the copper area should be connected to a heat sink or a metal plate for further heat dissipation.
• Can I use this module in a high-vibration environment?
  Yes, the QSB35024S12 is designed to withstand high-vibration environments. It has been tested to meet the IEC 60068-2-6 standard for vibration resistance. However, it's recommended to follow the recommended mounting and screw torque guidelines to ensure the module's reliability in such environments.
• How do I ensure the module's reliability in high-humidity environments?
  To ensure the module's reliability in high-humidity environments, XP Power recommends conformal coating the module and following the recommended storage and handling guidelines. Additionally, the module should be powered up and down slowly to prevent moisture ingress.
• What is the recommended input fuse rating for this module?
  XP Power recommends using a fuse with a rating of 10A to 15A, depending on the input voltage and current requirements of the application. The fuse should be able to handle the module's peak inrush current and provide adequate protection against overcurrent conditions.
• Can I use this module in a Class II (double-insulated) application?
  Yes, the QSB35024S12 is designed to meet the requirements for Class II (double-insulated) applications. It has a reinforced insulation system that provides a high level of safety and reliability in such applications.
