QX133A32.00000B15R - Qantek

QX133A32.00000B15R Details

• Manufacturer Part Number:

  QX133A32.00000B15R

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Contact Manufacturer

• Package Description:

  SMD, 4 PIN

• Manufacturer:

  QANTEK Technology Corporation

• Additional Feature:

  TRI-STATE; ENABLE/DISABLE FUNCTION

• Fall Time-Max:

  5 ns

• Frequency Adjustment-Mechanical:

  NO

• Frequency Stability:

  25%

• Mounting Feature:

  SURFACE MOUNT

• Number of Terminals:

  4

• Operating Frequency-Nom:

  32 MHz

• Operating Temperature-Max:

  85 °C

• Operating Temperature-Min:

  -40 °C

• Oscillator Type:

  HCMOS/TTL

• Output Load:

  15 pF

• Package Body Material:

  CERAMIC

• Package Equivalence Code:

  LCC4,.06X.08,50/38

• Packing Method:

  TR, 7 INCH

• Physical Dimension:

  2mm x 1.6mm x 0.8mm

• Rise Time-Max:

  5 ns

• Supply Current-Max:

  7 mA

• Supply Voltage-Max:

  3.465 V

• Supply Voltage-Min:

  3.135 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Symmetry-Max:

  60/40 %
