A thermal pad is recommended under the IC, and a solid ground plane on the bottom layer can help to dissipate heat. Additionally, keeping the thermal path short and using thermal vias can improve thermal performance.
To ensure stable output voltage, it's essential to follow the recommended capacitor values and types for input and output capacitors, and to keep the output capacitor close to the output pin. Additionally, a minimum load current of 1mA is recommended to maintain stability.
The maximum allowed input voltage transient is 18V for a duration of 100ms, according to the datasheet. However, it's recommended to limit the input voltage to 15V or less for continuous operation.
The R1202L521A-TR is rated for operation up to 125°C, but the output current may need to be derated at higher temperatures. It's essential to consider the thermal design and heat dissipation in high-temperature applications.
The power dissipation can be calculated using the formula: Pd = (Vin - Vout) x Iout. It's essential to consider the maximum input voltage, output current, and output voltage to ensure the regulator operates within its power dissipation limits.
Trust Checks
This model has been provided by community users.
Community Provided
This model has been verified by system checks.
System Verified
This model has been reviewed by community users.
Community Approved
Sponsored
R1202L521A-TR Overview
Use the download button to access the R1202L521A-TR schematic symbol, PCB footprint, and 3D model.
To find more CAD model downloads similar to this part, try a partial part number search, like R1202,
or try a keyword search, such as Switching Regulator or Controllers
