R5F51103ADNE#U0 - Renesas Electronics

R5F51103ADNE#U0 Details

• Manufacturer Part Number:

  R5F51103ADNE#U0

• Brand Name:

  Renesas

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Part Package Code:

  HWQFN

• Pin Count:

  48

• Manufacturer Package Code:

  PWQN0048KB

• HTS Code:

  8542.31.00.25

• Factory Lead Time:

  24 Weeks

• Manufacturer:

  Renesas Electronics Corporation

• YTEOL:

  0

• Has ADC:

  YES

• Bit Size:

  32

• Clock Frequency-Max:

  20 MHz

• DMA Channels:

  YES

• JESD-30 Code:

  S-XQCC-N48

• Length:

  7 mm

• Number of I/O Lines:

  34

• Number of Terminals:

  48

• PWM Channels:

  YES

• Package Body Material:

  UNSPECIFIED

• Package Code:

  HVQCCN

• Package Shape:

  SQUARE

• Package Style:

  CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE

• ROM (words):

  65536

• Speed:

  32 MHz

• Supply Voltage-Max:

  3.6 V

• Supply Voltage-Min:

  2.7 V

• Supply Voltage-Nom:

  3.3 V

• Surface Mount:

  YES

• Technology:

  CMOS

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  0.5 mm

• Terminal Position:

  QUAD

• Width:

  7 mm

• uPs/uCs/Peripheral ICs Type:

  MICROCONTROLLER
