RAC15-24SK/480 - RECOM Power

RAC15-24SK/480 Details

• Manufacturer Part Number:

  RAC15-24SK/480

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  DMA, MODULE,4LEAD,1.8

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Mainland China, Taiwan

• ECCN Code:

  EAR99

• Manufacturer:

  RECOM Power GmbH

• YTEOL:

  7

• Analog IC - Other Type:

  AC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CAN, CB, CE, CSA, C-UL-US, EN, IEC, UL

• Efficiency (Main Output):

  87%

• Input Voltage-Max:

  528 V

• Input Voltage-Min:

  85 V

• Input Voltage-Nom:

  100 V

• JESD-30 Code:

  R-XDMA-P4

• Length:

  52.5 mm

• Line Regulation-Max:

  2%

• Load Regulation-Max:

  2%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  4

• Operating Temperature-Max:

  90 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.625 A

• Output Voltage-Max:

  24.72 V

• Output Voltage-Min:

  23.28 V

• Output Voltage-Nom:

  24 V

• Package Body Material:

  UNSPECIFIED

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,4LEAD,1.8

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Protections:

  OVER CURRENT, OVER VOLTAGE, SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.053 Vrms

• Screening Level:

  EN/IEC 61010-1, EN/IEC/UL 62368-1

• Seated Height-Max:

  26 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Total Power Output-Max:

  15 W

• Trim/Adjustable Output:

  NO

• Warm-up Time:

  0.15 s

• Width:

  40 mm
