RACM16E-30SK/277 - RECOM Power

RACM16E-30SK/277 Details

• Manufacturer Part Number:

  RACM16E-30SK/277

• Part Life Cycle Code:

  Active

• Package Description:

  PACKAGE-4

• Reach Compliance Code:

  Unknown

• Country Of Origin:

  Mainland China, Taiwan

• ECCN Code:

  EAR99

• Manufacturer:

  RECOM Power GmbH

• YTEOL:

  6

• Analog IC - Other Type:

  AC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  ANSI; CE; CSA; EN; FCC; IEC; UKCA; UL

• Efficiency (Main Output):

  86%

• Input Voltage-Max:

  305 V

• Input Voltage-Min:

  85 V

• Input Voltage-Nom:

  115 V

• JESD-30 Code:

  R-PDMA-P4

• Length:

  52.7 mm

• Line Regulation-Max:

  0.2%

• Load Regulation-Max:

  1%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  4

• Operating Temperature-Max:

  65 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.533 A

• Output Voltage-Max:

  30.6 V

• Output Voltage-Min:

  29.4 V

• Output Voltage-Nom:

  30 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DMA

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Packing Method:

  TUBE

• Protections:

  OVER CURRENT; OVERLOAD; OVER VOLTAGE; SHORT CIRCUIT

• Screening Level:

  IEC 60601-1; 2 MOPP; IEC/EN 62368-1

• Seated Height-Max:

  23.5 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  16 W

• Trim/Adjustable Output:

  NO

• Warm-up Time:

  1.5 s

• Width:

  27.6 mm
