Schaffner recommends a multi-layer PCB with a solid ground plane, and thermal vias to dissipate heat. A minimum of 1 oz copper thickness is recommended. For thermal management, a heat sink with a thermal interface material is recommended.
To ensure EMC, Schaffner recommends following the guidelines in the datasheet for PCB layout, component placement, and shielding. Additionally, using a metal enclosure and proper cable shielding can help reduce electromagnetic interference.
The RB8522-16-3M0 is rated for operation from -40°C to +85°C. However, derating may be necessary for high-temperature applications. Consult the datasheet for specific derating guidelines.
Yes, the RB8522-16-3M0 can be used in redundant or parallel configurations. However, Schaffner recommends consulting their application notes and technical support for specific guidance on implementation and synchronization.
Schaffner recommends storing the RB8522-16-3M0 in its original packaging, away from direct sunlight, moisture, and extreme temperatures. Handling should be done with anti-static precautions, and the device should be soldered within 12 months of receipt.
