RBB10-2.0 - RECOM Power

RBB10-2.0 Details

• Manufacturer Part Number:

  RBB10-2.0

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  LGA, LGA25,5X5,90

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Mainland China, Taiwan

• ECCN Code:

  EAR99

• HTS Code:

  8542.39.00.60

• Date Of Intro:

  2018-10-05

• Manufacturer:

  RECOM Power GmbH

• YTEOL:

  8

• Analog IC - Other Type:

  SWITCHING REGULATOR

• Control Mode:

  CURRENT-MODE

• Control Technique:

  PULSE WIDTH MODULATION

• Input Voltage-Max:

  5.5 V

• Input Voltage-Min:

  2.3 V

• Input Voltage-Nom:

  5 V

• JESD-30 Code:

  S-MBGA-N25

• JESD-609 Code:

  e4

• Length:

  12.19 mm

• Number of Functions:

  1

• Number of Terminals:

  25

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  2 A

• Output Voltage-Max:

  5.5 V

• Output Voltage-Min:

  1 V

• Output Voltage-Nom:

  5 V

• Package Body Material:

  METAL

• Package Code:

  LGA

• Package Equivalence Code:

  LGA25,5X5,90

• Package Shape:

  SQUARE

• Package Style:

  GRID ARRAY

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Seated Height-Max:

  4 mm

• Surface Mount:

  YES

• Switcher Configuration:

  BUCK-BOOST

• Switching Frequency-Max:

  2550 kHz

• Technology:

  HYBRID

• Terminal Finish:

  Nickel/Gold (Ni/Au)

• Terminal Form:

  NO LEAD

• Terminal Pitch:

  2.29 mm

• Terminal Position:

  BOTTOM

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Width:

  12.19 mm
