RBE1KA20ATR - ROHM Semiconductor

Description: High Efficiency Type, 20V, 1A, SOT-353T, Schottky Barrier Diode

Download RBE1KA20ATR Model
Schematic
symbols
Schematic symbol is unavailable for download
PCB
footprints
PCB footprint is unavailable for download
3D
models
3D model is unavailable for download
PCB Footprints
RBE1KA20ATR - ROHM Semiconductor PCB footprint - Other - Other - TUMD5(H=0.82mm)
click to zoom
3D Models
RBE1KA20ATR - ROHM Semiconductor  - 3D model - Other - TUMD5(H=0.82mm)
click to zoom

RBE1KA20ATR Details

  • Manufacturer Part Number:

    RBE1KA20ATR

  • Rohs Code:

    Yes

  • Part Life Cycle Code:

    Not Recommended

  • Package Description:

    SC-113CA, SOT-353T, 5 PIN

  • ECCN Code:

    EAR99

  • HTS Code:

    8541.10.00.80

  • Manufacturer:

    ROHM Semiconductor

  • YTEOL:

    3

  • Additional Feature:

    HIGH RELIABILITY

  • Application:

    GENERAL PURPOSE

  • Configuration:

    SEPARATE, 2 ELEMENTS

  • Diode Element Material:

    SILICON

  • Diode Type:

    RECTIFIER DIODE

  • Forward Voltage-Max (VF):

    0.43 V

  • JESD-30 Code:

    R-PDSO-F5

  • Moisture Sensitivity Level:

    1

  • Non-rep Pk Forward Current-Max:

    3 A

  • Number of Elements:

    2

  • Number of Phases:

    1

  • Number of Terminals:

    5

  • Operating Temperature-Max:

    125 °C

  • Output Current-Max:

    1 A

  • Package Body Material:

    PLASTIC/EPOXY

  • Package Shape:

    RECTANGULAR

  • Package Style:

    SMALL OUTLINE

  • Peak Reflow Temperature (Cel):

    260

  • Rep Pk Reverse Voltage-Max:

    30 V

  • Reverse Current-Max:

    200 µA

  • Reverse Test Voltage:

    20 V

  • Surface Mount:

    YES

  • Technology:

    SCHOTTKY

  • Terminal Form:

    FLAT

  • Terminal Position:

    DUAL

  • Time@Peak Reflow Temperature-Max (s):

    30
