RCQ50110S15 - XP POWER

RCQ50110S15 Details

• Manufacturer Part Number:

  RCQ50110S15

• Pbfree Code:

  Yes

• Rohs Code:

  Yes

• Part Life Cycle Code:

  End Of Life

• Package Description:

  PACKAGE-8

• ECCN Code:

  EAR99

• Manufacturer:

  XP Power

• YTEOL:

  0

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CAN, CB, CE, CSA, EN, IEC, UKCA, UL

• Efficiency (Main Output):

  92%

• Input Voltage-Max:

  160 V

• Input Voltage-Min:

  66 V

• Input Voltage-Nom:

  110 V

• JESD-30 Code:

  R-PDMA-P8

• JESD-609 Code:

  e4

• Length:

  57.9 mm

• Line Regulation-Max:

  0.2%

• Load Regulation-Max:

  0.3%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  8

• Operating Temperature-Max:

  105 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  3.33 A

• Output Voltage-Max:

  16.5 V

• Output Voltage-Min:

  13.5 V

• Output Voltage-Nom:

  15 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,8LEAD,2

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  OVER VOLTAGE, OVER TEMPERATURE, SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.035 Vrms

• Screening Level:

  UL 62328-1

• Seated Height-Max:

  12.75 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Finish:

  GOLD

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  50 W

• Trim/Adjustable Output:

  YES

• Width:

  36.8 mm
