RDH60072WS48 - XP POWER

RDH60072WS48 Details

• Manufacturer Part Number:

  RDH60072WS48

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Active

• Package Description:

  FULL BRICK PACKAGE-16/14

• ECCN Code:

  EAR99

• Date Of Intro:

  2019-06-14

• Manufacturer:

  XP Power

• YTEOL:

  7

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CE, EN, UKCA, UL

• Efficiency (Main Output):

  88%

• Input Voltage-Max:

  160 V

• Input Voltage-Min:

  43 V

• Input Voltage-Nom:

  72 V

• JESD-30 Code:

  R-PDMA-P14

• JESD-609 Code:

  e3

• Length:

  116.8 mm

• Line Regulation-Max:

  0.2%

• Load Regulation-Max:

  0.5%

• Number of Functions:

  2

• Number of Outputs:

  1

• Number of Terminals:

  14

• Operating Temperature-Max:

  100 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  12.5 A

• Output Voltage-Max:

  52.8 V

• Output Voltage-Min:

  28.8 V

• Output Voltage-Nom:

  48 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DMA

• Package Equivalence Code:

  MODULE,14/16LEAD,4.2

• Package Shape:

  RECTANGULAR

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Peak Reflow Temperature (Cel):

  NOT SPECIFIED

• Protections:

  OVER LOAD, OVER VOLTAGE, OVER TEMPERATURE, SHORT CIRCUIT

• Ripple Voltage (Main Out):

  0.169 Vrms

• Screening Level:

  EN 62368-1

• Seated Height-Max:

  13.2 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Terminal Finish:

  Matte Tin (Sn) - with Nickel (Ni) barrier

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Time@Peak Reflow Temperature-Max (s):

  NOT SPECIFIED

• Total Power Output-Max:

  600 W

• Trim/Adjustable Output:

  YES

• Warm-up Time:

  0.25 s

• Width:

  61 mm
