REC10-2405S/H2/M Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal thermal performance?
  RECOM Power Inc recommends a PCB layout with a large copper area connected to the module's thermal pad to ensure good heat dissipation. A minimum of 2 oz copper thickness is recommended, and the copper area should be connected to a heat sink or a metal plate for further heat dissipation.
• Can I use this module in a high-vibration environment?
  Yes, the REC10-2405S/H2/M is designed to withstand high-vibration environments. However, it's recommended to follow the recommended PCB layout and mounting guidelines to ensure the module is securely attached to the PCB and can withstand vibrations up to 10G.
• What is the maximum capacitance load that can be connected to the output?
  The maximum capacitance load that can be connected to the output of the REC10-2405S/H2/M is 10uF. Exceeding this value may cause instability or oscillation in the output voltage.
• Can I use this module in a humid or wet environment?
  The REC10-2405S/H2/M has a conformal coating that provides some protection against humidity and moisture. However, it's not recommended to use the module in an environment with high humidity or direct exposure to water. If the module is to be used in a humid environment, it's recommended to add additional protection such as a sealed enclosure or conformal coating.
• What is the recommended input fuse rating?
  The recommended input fuse rating for the REC10-2405S/H2/M is 2A slow-blow. This will provide protection against input overcurrent and ensure safe operation of the module.
