REC10-2405SZ/H2/M Frequently Asked Questions (FAQs)

• What is the recommended PCB layout for optimal thermal performance?
  RECOM recommends a PCB layout with a large copper area connected to the module's thermal pad to ensure good heat dissipation. A minimum of 2 oz copper thickness is recommended, and the copper area should be connected to a heat sink or a metal plate for further heat dissipation.
• Can I use this module in a high-vibration environment?
  Yes, the REC10-2405SZ/H2/M is designed to withstand high vibrations. However, it's essential to ensure that the module is properly secured to the PCB and that the PCB is designed to withstand the vibrations. RECOM recommends following the IPC-9592 standard for vibration testing.
• What is the maximum allowed capacitance for the input and output capacitors?
  RECOM recommends using capacitors with a maximum capacitance of 10uF for the input and 22uF for the output. Exceeding these values may affect the module's stability and performance.
• Can I use this module in a humid environment?
  The REC10-2405SZ/H2/M is designed to operate in a humid environment, but it's essential to ensure that the module is properly sealed and that the PCB is designed to withstand humidity. RECOM recommends following the IPC-J-STD-001 standard for humidity testing.
• What is the recommended input voltage range for optimal performance?
  While the datasheet specifies a wide input voltage range, RECOM recommends operating the module within the 18V to 36V range for optimal performance and efficiency.
