REC8E-4824S/CTRL/X1 - RECOM Power

REC8E-4824S/CTRL/X1 Details

• Manufacturer Part Number:

  REC8E-4824S/CTRL/X1

• Rohs Code:

  Yes

• Part Life Cycle Code:

  Obsolete

• Package Description:

  DMA,

• Reach Compliance Code:

  Compliant

• Country Of Origin:

  Mainland China, Taiwan

• ECCN Code:

  EAR99

• Manufacturer:

  RECOM Power GmbH

• YTEOL:

  0

• Analog IC - Other Type:

  DC-DC REGULATED POWER SUPPLY MODULE

• Approvals:

  CB, CSA, EN, IEC, UL

• Control Mode:

  VOLTAGE-MODE

• Efficiency (Main Output):

  83%

• Input Voltage-Max:

  60 V

• Input Voltage-Min:

  20 V

• Input Voltage-Nom:

  48 V

• JESD-30 Code:

  S-PDMA-P6

• Length:

  25.4 mm

• Line Regulation-Max:

  0.4%

• Load Regulation-Max:

  0.5%

• Number of Functions:

  1

• Number of Outputs:

  1

• Number of Terminals:

  6

• Operating Temperature-Max:

  75 °C

• Operating Temperature-Min:

  -40 °C

• Output Current-Max:

  0.333 A

• Output Voltage-Max:

  24.24 V

• Output Voltage-Min:

  23.76 V

• Output Voltage-Nom:

  24 V

• Package Body Material:

  PLASTIC/EPOXY

• Package Code:

  DMA

• Package Shape:

  SQUARE

• Package Style:

  MICROELECTRONIC ASSEMBLY

• Protections:

  SHORT CIRCUIT; OVER CURRENT

• Ripple Voltage (Main Out):

  0.03535 Vrms

• Seated Height-Max:

  11 mm

• Surface Mount:

  NO

• Technology:

  HYBRID

• Temperature Grade:

  OTHER

• Terminal Form:

  PIN/PEG

• Terminal Position:

  DUAL

• Total Power Output-Max:

  8 W

• Trim/Adjustable Output:

  NO

• Width:

  25.4 mm
